Waterproof Split core CT
IP67 Waterproof outdoor split core current transformer is built with silicone steel core and is potted for outdoor use. In addition, it is designed for easy installation on ground potential conductors.
Key Features
- For outdoor use, level of protection: IP67
- Split core design for fast and easy installation
Applications
Specifications
Electrical
Mechanical Environmental
Model Variants
Select the appropriate model based on your window size and input / output requirements.
| Model | Window Size | Input | Output | Accuracy | Weight | MODEL SPECS |
|---|---|---|---|---|---|---|
| FSCT-20 | 20mm | 100-300A | 1A ,5A,mA ,mV,V | 0.5% ,1.0% | 200g | |
| FSCT-30 | 30mm | 100-600A | 1A ,5A,mA ,mV,V | 0.5% ,1.0% | 300g | |
| FSCT-35 | 35mm | 100-800A | 1A ,5A,mA ,mV,V | 0.5% ,1.0% | 700g | |
| FSCT-36 | 36mm | 100-800A | 1A ,5A,mA ,mV,V | 0.5% ,1.0% | 800g | |
| FSCT-50 | 50mm | 100-1500A | 1A ,5A,mA ,mV,V | 0.5% ,1.0% | 1200g | |
| FSCT-60 | 60mm | 100-2000A | 1A ,5A,mA ,mV,V | 0.5% ,1.0% | 1500g |
Ready to Order the Waterproof Split core CT?
Jiangyin Spark provides reliable OEM & ODM services with ISO-certified manufacturing. Fast delivery within 7-10 days for 10K pcs. Free standard samples available.
Provide Specs
Share your input current, output, lead wire length, terminal requirements, and window size.
Test Samples
We recommend a model and provide free standard samples shipped within 3 days via your freight account.
Fast Production
Once approved, standard lead time is just 10-15 days from order receipt.
UL listed (E498920) · CE · UKCA · RoHS · ISO 9001 · ISO 14001 · ISO 45001
